75 AMP DUAL ROW TERMINAL BLOCKS
- Product SKU: GE476
- Product Name: 75 AMP DUAL ROW TERMINAL BLOCKS
- Manufacturer: PHILMORE
Dual-row terminal blocks, 75A, 600V. Center spacing: .687" or 11/16" (17.45mm). Screw size: #10.32 philslot screws. Torque rating: 20 in-lb. Wire range: #6-14 AWG CU. Mounting: #10 screws, distance between barriers: .56" (14.3mm). Operating temp: 130ºC max., -40ºC min. Breakdown voltage: 7500V. Materials: molded base UL rated 94VO thermoplastic; terminal plating: tin over brass; screws: zinc-plated steel. UL/CSA, IEC compliance, CE Certified.
Part No. | No. poles | "A" dim. | "B" dim. |
---|---|---|---|
GE477 | 2 | 2.51" | 2.06" |
GE478 | 3 | 3.20" | 2.75" |
GE479 | 4 | 3.89" | 3.44" |
GE480 | 5 | 4.58" | 4.13" |
GE481 | 6 | 5.26" | 4.81" |
GE482 | 7 | 5.95" | 5.50" |
GE483 | 8 | 6.64" | 6.19" |
GE484 | 9 | 7.33" | 6.88" |
GE485 | 10 | 8.01" | 7.56" |
GE486 | 12 | 9.39" | 8.94" |
Condition: New
- Product Availability: Available
